prices for photovoltaic solar panel 50watts

prices for photovoltaic solar panel 50watts

prices for photovoltaic solar panel 50watts
prices for photovoltaic solar panel 50wattsprices for photovoltaic solar panel 50wattsprices for photovoltaic solar panel 50wattsprices for photovoltaic solar panel 50wattsprices for photovoltaic solar panel 50watts
CategoriesPoly Solar Panel
AlbumView larger image
Brandsufusolar,saikangguangdian,shanggui
ModelSFP70W-100W
Maximum power voltage17.9V-18V
Maximum power currentTUV3.91A-5.56A/CE/ISO
Open circult voltage21.48V-21.6V
Maximum system voltage1000V DC(IEC)
Short circuit current4.3A-6.11A
Power Tolerance(%)0~+3
Pmax Temperature Coefficient-0.42%/℃
Storage TemperatureFrom-40 to+60℃
Operating TemperatureFrom-40 to+85℃
FOB portTianjin
Terms of PaymentT/T
Download DOC
Update Time2018-12-12
Detail Information
prices for photovoltaic solar panel 50watts

Overview

· High cell efficiency PV solar panel with quality silicon material for long term output stability and reliability.

· Rigorous quality control to meet the highest international standards.

· High transmittance, low iron tempered glass with enhanced stiffness and impact resistance.

· Unique frame design with high mechanical strength for easy installation.

· Advanced encapsulation material with multilayer sheet lamination to provide long-life and enhanced cell performance.

· Outstanding electrical performance under high temperature and low irradiance conditions.


Applications

· Commercial/ industrial building PV solar roof-top off-grid systems.

· Residential PV solar roof-top off-grid systems.

· Any commercial / industrial ground mount off-grid systems.

· Other off-grid industrial and commercial solar PV applications.

ELECTRICAL CHARACTERISTICS(STC*)
ELECTRICAL CHARACTERISTICS(STC*)
Model No.(SFP)
130W
135W
140W
145W
150W
Maximum Power at STC(Pmax)
130W
135W
140W
145W
150W
Maximum Power Voltage(Vmp)
17.65V
17.70V
17.80V
18.00V
18.30V
Maximum Power Current(Imp)
7.37A
7.63A
7.87A
8.06A
8.20A
Open Circult Voltage(Voc)
21.18V
21.24V
21.36V
21.60V
21.96V
Short Circuit Current(Isc)
8.10A
8.39A
8.65A
8.86A
9.02A
Module Effciency(%)
13.86
14.39
14.93
15.46
16.00
Maximum System Voltage(V)
1000V DC(IEC)
Maximum Series Fuse Rating(A)
15A
Power Tolerance(%)
0~+3%
NOCT
45±2℃
Pmax Temperature Coefficient
-0.46%/℃
Voc Temperature Coefficient
-0.346%/℃
Isc Temperature Coefficient
0.065%/℃
Storage Temperature
From -40to+60℃
Operating Temperature
From -40to+85℃
*STC(Standard Test Condition):Irradiance 1000w/m2,module temperature 25℃,AM1.5
Best in Class AAA solar simulator(IEC 60904-9)is used,with power measurement uncertainty within ±3%
Detailed Image

Solar Cell


High Efficiency PV Cells

Appearance Consistency

Color sorting ensure consistent appearance on each module Anti-PID.

Glass

Antireflective glass

Translucency of normal luminance is increased by 2%

Module efficiency is increased by 2%

Self-cleaning function

Service life is as long as 25 years (30 years optional)

Frame

Conventional frame

Silver or black frames are optional

Boost bearing capability and prolong service life

Serrated-clip design tensile strength

Seal-lip designglue injection
Production process
Packing & Delivery

Warranty

· 10 year limited product warranty on materials and workmanship.

· 25 year limited power warranty on power output.

· ≥90% power output assurance for 10 years and ≥80% power output assurance for 25 years.

· Refer to warranty document for detailed warranty information.

Certifications

· TUV(IEC61215 IEC61730)

· CE

· ISO




Packaging Configuration

Packing Configuration

26 pcs/box

Quantity/Pallet

52 pcs/pallet

Loading Capacity

312pcs/20ft ; 784 pcs/40ft

Packaging & Delivery

Packaging Details:packing is suitable for sea transportation

Delivery Time:within 10 days after receiving down payment

Our Company
70w-100w home energy saving solar panels
Qinhuangdao Sufu Electronic Co.,Ltd is a modern solar modules,solar system solutions and serivce supplier.Our solar products are range from solar modules to solar power systems,solar street lights,solar multi-functional chargers,solar pump and photovoltaic power stations,bulding attached photovoltaic(BAPV),building integrated photovoltaic(BIPV) design and construction.
Covering over workshops of 30,000㎡,the first phase invertment is 20 million RMB with now our annual production capacity of 20MW for both mono and poly solar panels.
Sufu has been offering the world reliable and renewable products which are internationally certified with TUV,CE,IEC and ISO9001 etc.
The product applies to a wide range of clients including Australia,India,Japan,Korea,South America,Middle-ease, Southeast Asia,Africa and other countries.
