Home > Products > Poly Solar Panel >

solar panel sale for Poly Solar Panel for off Grid Solar Module System 10 kw

solar panel sale for Poly Solar Panel for off Grid Solar Module System 10 kw

solar panel sale for Poly Solar Panel for off Grid Solar Module System 10 kw
solar panel sale for Poly Solar Panel for off Grid Solar Module System 10 kwsolar panel sale for Poly Solar Panel for off Grid Solar Module System 10 kwsolar panel sale for Poly Solar Panel for off Grid Solar Module System 10 kwsolar panel sale for Poly Solar Panel for off Grid Solar Module System 10 kwsolar panel sale for Poly Solar Panel for off Grid Solar Module System 10 kw
CategoriesPoly Solar Panel
AlbumView larger image
Brandsufusolar,saikangguangdian,shanggui
ModelSFM130w
Max. Power130W
CertificateTUV/CE/ISO
Warranty25 Years Output Power Guarantee
Frame MaterialAnodized Aluminum Alloy
Front Cover(Material/Thickness)Tempered & Low Iron Glass/3.2mm
EncapsulateEthylene Vinyl Acetate
rated voltage17.75
rated current21.3
FOB portTianjin
Terms of PaymentT/T
Download DOC
Update Time2018-12-12
Detail Information
solar panel sale for Poly Solar Panel for off Grid Solar Module System 10 kw
High cell efficiency PV solar panel with quality silicon material for long term output stability and reliability.
Rigorous quality control to meet the highest international standards.
High transmittance, low iron tempered glass with enhanced stiffness and impact resistance.
Unique frame design with high mechanical strength for easy installation.
Advanced encapsulation material with multilayer sheet lamination to provide long-life and enhanced cell performance.
ELECTRICAL CHARACTERISTICS(STC*)
ELECTRICAL CHARACTERISTICS(STC*)
Model No.(SFP)130W135W140W145W150W
Maximum Power at STC(Pmax)130W135W140W145W150W
Maximum Power Voltage(Vmp)17.65V17.70V17.80V18.00V18.30V
Maximum Power Current(Imp)7.37A7.63A7.87A8.06A8.20A
Open Circult Voltage(Voc)21.18V21.24V21.36V21.60V21.96V
Short Circuit Current(Isc)8.10A8.39A8.65A8.86A9.02A
Module Effciency(%)13.8614.3914.9315.4616.00
Maximum System Voltage(V)1000V DC(IEC)
Maximum Series Fuse Rating(A)15A
Power Tolerance(%)0+3%
NOCT45±2
Pmax Temperature Coefficient-0.46%/
Voc Temperature Coefficient-0.346%/
Isc Temperature Coefficient0.065%/
Storage Temperature From -40to+60
Operating Temperature From -40to+85
*STC(Standard Test Condition):Irradiance 1000w/m2,module temperature 25,AM1.5
Best in Class AAA solar simulator(IEC 60904-9)is used,with power measurement uncertainty within ±3%
Detailed Image

Solar Cell


High Efficiency PV Cells

Appearance Consistency

Color sorting ensure consistent appearance on each module Anti-PID.

Glass

Antireflective glass

Translucency of normal luminance is increased by 2%

Module efficiency is increased by 2%

Self-cleaning function

Service life is as long as 25 years (30 years optional)

Frame

Conventional frame

Silver or black frames are optional

Boost bearing capability and prolong service life

Serrated-clip design tensile strength

Seal-lip designglue injection
Production process
Packing & Delivery
Our Company
Qinhuangdao Sufu Electronic Co.,Ltd is a modern solar modules,solar system solutions and serivce supplier.Our solar products are range from solar modules to solar power systems,solar street lights,solar multi-functional chargers,solar pump and photovoltaic power stations,bulding attached photovoltaic(BAPV),building integrated photovoltaic(BIPV) design and construction.
Covering over workshops of 30,000㎡,the first phase invertment is 20 million RMB with now our annual production capacity of 20MW for both mono and poly solar panels.
Sufu has been offering the world reliable and renewable products which are internationally certified with TUV,CE,IEC and ISO9001 etc.
The product applies to a wide range of clients including Australia,India,Japan,Korea,South America,Middle-ease, Southeast Asia,Africa and other countries.
