Home > Products > Poly Solar Panel >

130w 150w poly solar panel for house price

130w 150w poly solar panel for house price

130w 150w poly solar panel for house price
130w 150w poly solar panel for house price130w 150w poly solar panel for house price130w 150w poly solar panel for house price130w 150w poly solar panel for house price130w 150w poly solar panel for house price
CategoriesPoly Solar Panel
AlbumView larger image
Max. Power130W
Warranty25 Years Output Power Guarantee
Frame MaterialAnodized Aluminum Alloy
Front Cover(Material/Thickness)Tempered & Low Iron Glass/3.2mm
EncapsulateEthylene Vinyl Acetate
rated voltage17.75
rated current21.3
Type of ConnectorMC4
Cell Size(mm)156*156(D200)
FOB portTianjin
Terms of PaymentT/T
Download DOC
Update Time2019-02-23
Detail Information
130w 150w poly solar panel for house price
High cell efficiency PV solar panel with quality silicon material for long term output stability and reliability.
Rigorous quality control to meet the highest international standards.
High transmittance, low iron tempered glass with enhanced stiffness and impact resistance.
Unique frame design with high mechanical strength for easy installation.
Advanced encapsulation material with multilayer sheet lamination to provide long-life and enhanced cell performance.
Model No.(SFP)130W135W140W145W150W
Maximum Power at STC(Pmax)130W135W140W145W150W
Maximum Power Voltage(Vmp)17.65V17.70V17.80V18.00V18.30V
Maximum Power Current(Imp)7.37A7.63A7.87A8.06A8.20A
Open Circult Voltage(Voc)21.18V21.24V21.36V21.60V21.96V
Short Circuit Current(Isc)8.10A8.39A8.65A8.86A9.02A
Module Effciency(%)13.8614.3914.9315.4616.00
Maximum System Voltage(V)1000V DC(IEC)
Maximum Series Fuse Rating(A)15A
Power Tolerance(%)0+3%
Pmax Temperature Coefficient-0.46%/
Voc Temperature Coefficient-0.346%/
Isc Temperature Coefficient0.065%/
Storage Temperature From -40to+60
Operating Temperature From -40to+85
*STC(Standard Test Condition):Irradiance 1000w/m2,module temperature 25,AM1.5
Best in Class AAA solar simulator(IEC 60904-9)is used,with power measurement uncertainty within ±3%
Detailed Image

Solar Cell

High Efficiency PV Cells

Appearance Consistency

Color sorting ensure consistent appearance on each module Anti-PID.


Antireflective glass

Translucency of normal luminance is increased by 2%

Module efficiency is increased by 2%

Self-cleaning function

Service life is as long as 25 years (30 years optional)


Conventional frame

Silver or black frames are optional

Boost bearing capability and prolong service life

Serrated-clip design tensile strength

Seal-lip designglue injection
Production process
Packing & Delivery
Our Company
Qinhuangdao Sufu Electronic Co.,Ltd is a modern solar modules,solar system solutions and serivce supplier.Our solar products are range from solar modules to solar power systems,solar street lights,solar multi-functional chargers,solar pump and photovoltaic power stations,bulding attached photovoltaic(BAPV),building integrated photovoltaic(BIPV) design and construction.
Covering over workshops of 30,000㎡,the first phase invertment is 20 million RMB with now our annual production capacity of 20MW for both mono and poly solar panels.
Sufu has been offering the world reliable and renewable products which are internationally certified with TUV,CE,IEC and ISO9001 etc.
The product applies to a wide range of clients including Australia,India,Japan,Korea,South America,Middle-ease, Southeast Asia,Africa and other countries.
