chinese price solar panels 50 watts for sale specification

chinese price solar panels 50 watts for sale specification

chinese price solar panels 50 watts for sale specification
chinese price solar panels 50 watts for sale specificationchinese price solar panels 50 watts for sale specificationchinese price solar panels 50 watts for sale specificationchinese price solar panels 50 watts for sale specificationchinese price solar panels 50 watts for sale specification
CategoriesPoly Solar Panel
AlbumView larger image
Brandsufusolar,saikangguangdian,shanggui
ModelSFP50W
Vmp17.9V
Imp3.91A
Module efficiency(%)13.77
Maximum system voltage1000V DC(IEC)
Junction BoxIP65 rated
Weight (KG)6
Dimension(L×W×H mm)770×660×30
Frame MaterialAnodized Aluminum Alloy
Solar cellsMonocrystalline
Front Cover(Material/Thickness)Tempered & Low Iron Glass/3.2mm
FOB porttianjin port or customized
Terms of PaymentT/T
Download DOC
Update Time2018-12-12
Detail Information

chinese price solar panels 50 watts for sale specification



Quick Details

Dielectric Insulation Voltage:3000V

Operating Temperature(℃):40~+85

Storage Temperature(℃):-40~+85

Packaging & Delivery

Packaging Details:packing is suitable for sea transportation

Delivery Time:within 10 days after receiving down payment




Overview

· High cell efficiency PV solar panel with quality silicon material for long term output stability and reliability.

· Rigorous quality control to meet the highest international standards.

· High transmittance, low iron tempered glass with enhanced stiffness and impact resistance.

· Unique frame design with high mechanical strength for easy installation.

· Advanced encapsulation material with multilayer sheet lamination to provide long-life and enhanced cell performance.

· Outstanding electrical performance under high temperature and low irradiance conditions.

·  60 Back-Contact polycrystalline Si solar cells (approx. 18.32%).


Applications

· Commercial/ industrial building PV solar roof-top off-grid systems.

· Residential PV solar roof-top off-grid systems.

· Any commercial / industrial ground mount off-grid systems.

· Other off-grid industrial and commercial solar PV applications.

Warranty

· 10 year limited product warranty on materials and workmanship.

· 25 year limited power warranty on power output.

· ≥90% power output assurance for 10 years and ≥80% power output assurance for 25 years.

· Refer to warranty document for detailed warranty information.

Certifications

· TUV(IEC61215 IEC61730)

· CE

· ISO


Electrical Characteristics

All specified Parameters are at STC 25℃Ambient, 1000W/ m irradiance and AM 1.5


Mechanical Characteristics



Specifications & Datasheet
Module No.PmaxVmp[V]Imp[A]Voc[V]Isc[A]Module efficiency(%)Junction BoxWeight (KG)Dimension(L×W×H mm)
SFP5W5W17.45 0.29 20.94 0.32 7.64 IP65 rated1.20 350×187×17
SFP10W10W17.59 0.57 21.01 0.63 10.20 IP65 rated1.80 350×280×17
SFP15W15W17.61 0.85 21.13 0.94 10.71 IP65 rated2.30 400×350×25
SFP20W20W17.65 1.13 21.18 1.37 10.88 IP65 rated1.90 525×350×25
SFP25W25W17.60 1.42 21.12 1.55 13.61 IP65 rated2.30 525×350×25
SFP30W30W17.65 1.70 21.18 1.86 16.33 IP65 rated2.70 535×510×25
SFP40W40W17.70 2.26 21.24 2.04 12.37 IP65 rated6.20 660×490×25
SFP45W45W17.78 2.53 21.34 2.78 13.91 IP65 rated6.20 660×490×25
SFP50W50W17.80 2.81 21.36 3.08 15.46 IP65 rated6.30 660×490×25
SFP60W60W17.82 3.37 21.38 3.40 11.81 IP65 rated6.30 770×660×30
SFP65W65W17.85 3.64 21.42 3.68 12.79 IP65 rated6.30 770×660×30
SFP70W70W17.90 3.91 21.48 3.99 13.77 IP65 rated6.00 770×660×30
SFP75W75W17.93 4.18 21.52 4.29 14.76 IP65 rated6.30 770×660×30
SFP75W75W17.96 4.18 21.55 4.59 12.63 IP65 rated6.30 900×660×30
SFP80W80W17.97 4.45 21.56 4.89 13.47 IP65 rated7.90 900×660×31
SFP85W85W18.00 4.72 21.60 5.19 14.31 IP65 rated8.30 900×660×32
SFP90W90W18.05 4.99 21.66 5.48 15.15 IP65 rated8.30 900×660×33
SFP95W95W18.07 5.26 21.68 5.78 14.25 IP65 rated8.30 1010×660×30
SFP100W100W18.00 5.26 21.60 6.08 12.44 IP65 rated9.00 1200×670×30
NOCT45±2
Pmax Temperature Coefficient0.42%/
Voc Temperature Coefficient0.32/
Isc Temperature Coefficient0.06/
Storage Temperature From-40 to +60
Operating TemperatureFrom-40 to +85
Frame MaterialAnodized Aluminum Alloy
Solar cellsMonocrystalline
Front Cover(Material/Thickness)Tempered & Low Iron Glass/3.2mm
EncapsulateEthylene Vinyl Acetate
Solar CablesOptional
ConnectorsOptional
